How to Append Text Or Symbol to Tooltip Of Chart.js?

12 minutes read

To append text or a symbol to a tooltip in Chart.js, you can use the 'callbacks' property of the options object provided when creating the chart.


Here's an example of how you can append a symbol or text to the tooltip using a callback function:

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
18
19
20
21
22
var chartOptions = {
    tooltips: {
        callbacks: {
            label: function(tooltipItem, data) {
                var label = data.datasets[tooltipItem.datasetIndex].label || '';
                label += ': ' + tooltipItem.yLabel; // Append the yLabel value to the label

                // Append a symbol or text to the label
                label += ' %'; // Example: Appending a percentage symbol

                return label;
            }
        }
    }
};

// Create and configure the chart
var myChart = new Chart(ctx, {
    type: 'line',
    data: data,
    options: chartOptions
});


In this example, the label function is used to generate the tooltip label for each data point. It retrieves the dataset label and appends the yLabel value to it. Additionally, you can append another symbol or text by concatenating it to the label variable.


Feel free to customize the callback function according to your chart needs. You can also refer to the official Chart.js documentation for more information about the available tooltip callbacks and customization options.

Best Javascript Books to Read in 2024

1
JavaScript: The Comprehensive Guide to Learning Professional JavaScript Programming (The Rheinwerk Computing)

Rating is 5 out of 5

JavaScript: The Comprehensive Guide to Learning Professional JavaScript Programming (The Rheinwerk Computing)

2
JavaScript: The Definitive Guide: Master the World's Most-Used Programming Language

Rating is 4.9 out of 5

JavaScript: The Definitive Guide: Master the World's Most-Used Programming Language

3
JavaScript from Beginner to Professional: Learn JavaScript quickly by building fun, interactive, and dynamic web apps, games, and pages

Rating is 4.8 out of 5

JavaScript from Beginner to Professional: Learn JavaScript quickly by building fun, interactive, and dynamic web apps, games, and pages

4
Head First JavaScript Programming: A Brain-Friendly Guide

Rating is 4.7 out of 5

Head First JavaScript Programming: A Brain-Friendly Guide

5
Web Design with HTML, CSS, JavaScript and jQuery Set

Rating is 4.6 out of 5

Web Design with HTML, CSS, JavaScript and jQuery Set

6
Learning JavaScript Design Patterns: A JavaScript and React Developer's Guide

Rating is 4.5 out of 5

Learning JavaScript Design Patterns: A JavaScript and React Developer's Guide

7
JavaScript All-in-One For Dummies

Rating is 4.4 out of 5

JavaScript All-in-One For Dummies

8
JavaScript and jQuery: Interactive Front-End Web Development

Rating is 4.3 out of 5

JavaScript and jQuery: Interactive Front-End Web Development

9
Eloquent JavaScript, 3rd Edition: A Modern Introduction to Programming

Rating is 4.2 out of 5

Eloquent JavaScript, 3rd Edition: A Modern Introduction to Programming


How to append text to tooltip of chart.js?

To append text to the tooltip of a chart.js chart, you can use the callbacks option provided by chart.js. Here's an example of how you can achieve it:

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
18
19
20
var chart = new Chart(ctx, {
  type: 'bar',
  data: {
    labels: ['A', 'B', 'C'],
    datasets: [{
      label: 'Data',
      data: [10, 20, 30]
    }]
  },
  options: {
    tooltips: {
      callbacks: {
        // Append text to the tooltip body
        afterBody: function(tooltipItems) {
          return 'Extra text';
        }
      }
    }
  }
});


In this example, we define a chart.js bar chart with a single dataset. The tooltips option contains a callbacks object that is used to specify custom behavior for the tooltips. The afterBody callback function appends the desired text to the tooltip body. In this case, it simply returns the string 'Extra text'.


You can customize the appended text by modifying the afterBody callback function. You can access the tooltip items via the tooltipItems parameter and use its properties, such as index or datasetIndex, to retrieve the relevant data for appending.


How to toggle the visibility of the tooltip in chart.js?

You can toggle the visibility of tooltips in Chart.js by using the enabled property of the tooltips configuration object. Here is an example of how to do it:

  1. In your chart configuration, add the tooltips object with the enabled property set to false:
1
2
3
4
5
6
7
8
9
var chartConfig = {
  // other chart options...
  options: {
    tooltips: {
      enabled: false
    },
    // other options...
  }
};


  1. Next, create a function to toggle the visibility of the tooltips. This function will change the enabled property to true or false based on the current value:
1
2
3
4
5
function toggleTooltips() {
  var tooltipsEnabled = chartConfig.options.tooltips.enabled;
  chartConfig.options.tooltips.enabled = !tooltipsEnabled;
  chart.update(); // call update function to apply changes
}


  1. Finally, call the toggleTooltips function when you want to toggle the visibility of tooltips. This can be triggered by a button click or any other event:
1
<button onclick="toggleTooltips()">Toggle Tooltips</button>


Now, when you click the button, it will toggle the visibility of tooltips in the chart.


How to display additional data in the tooltip using chart.js?

To display additional data in the tooltip using Chart.js, you can make use of the callbacks property of the tooltip option. Within this callback function, you can access the tooltip label and index to retrieve the additional data and display it accordingly.


Here's an example of how you can achieve this:

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
var chartData = {
  labels: ['Label1', 'Label2', 'Label3'],
  datasets: [{
    data: [10, 20, 30],
    additionalData: ['Additional Data 1', 'Additional Data 2', 'Additional Data 3']
  }]
};

var config = {
  type: 'bar',
  data: chartData,
  options: {
    tooltips: {
      callbacks: {
        label: function(tooltipItem, data) {
          var label = data.labels[tooltipItem.index];
          var value = data.datasets[tooltipItem.datasetIndex].data[tooltipItem.index];
          var additionalData = data.datasets[tooltipItem.datasetIndex].additionalData[tooltipItem.index];
          return label + ': ' + value + ' (' + additionalData + ')';
        }
      }
    }
  }
};

var ctx = document.getElementById('myChart').getContext('2d');
new Chart(ctx, config);


In this example, we have a bar chart with additional data stored in the additionalData property of each dataset. We use the label callback to access this additional data, retrieve it based on the tooltip index, and append it to the tooltip label.


Make sure to adjust the chartData object to match your data structure and modify the callback function accordingly if needed.


How to add symbols to tooltip of chart.js?

To add symbols to the tooltip of a chart using Chart.js, you can make use of the title and label configuration options.


Below is an example of how you can customize the tooltip to include symbols:

  1. Define the symbols as an array or object. For example:
1
const symbols = ["★", "✩", "⦿", "●", "✪"];


  1. In the options object of your chart configuration, use the callbacks property to define a label callback function. This function determines the tooltip text and can be customized to include symbols.
 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
const options = {
  tooltips: {
    callbacks: {
      label: function (tooltipItem, data) {
        // Retrieve the dataset index and current value
        const datasetIndex = tooltipItem.datasetIndex;
        const value = data.datasets[datasetIndex].data[tooltipItem.index];

        // Add a symbol using the modulo operator (%) to loop through the symbol array
        const symbol = symbols[tooltipItem.index % symbols.length];

        // Customize the tooltip label text
        return symbol + ": " + value;
      }
    }
  }
};


  1. Use the options object within your chart configuration when creating the chart.


Here's an example of chart configuration using these steps:

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
const chartConfig = {
  type: 'bar',
  data: {
    labels: ['USA', 'Canada', 'UK', 'Australia', 'Germany'],
    datasets: [{
      label: 'Population',
      data: [331, 38, 66, 25, 83],
      backgroundColor: 'rgba(54, 162, 235, 0.8)'
    }]
  },
  options: {
    tooltips: {
      callbacks: {
        label: function (tooltipItem, data) {
          const datasetIndex = tooltipItem.datasetIndex;
          const value = data.datasets[datasetIndex].data[tooltipItem.index];
          const symbol = symbols[tooltipItem.index % symbols.length];
          return symbol + ": " + value;
        }
      }
    }
  }
};

const myChart = new Chart(document.getElementById('myChart'), chartConfig);


With this configuration, the tooltips for the chart will display symbols followed by the corresponding data value.


How to change the tooltip background color in chart.js?

To change the tooltip background color in Chart.js, you need to modify the tooltip background color property in the chart's options object. Here's an example:

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
var chartOptions = {
  tooltips: {
    backgroundColor: 'rgba(255, 0, 0, 0.8)' // Set the tooltip background color as red with opacity 0.8
  }
};

var myChart = new Chart(ctx, {
  type: 'bar',
  data: data,
  options: chartOptions
});


In the above example, we set the tooltip background color to red with an opacity of 0.8 using the backgroundColor property inside the tooltips object in the chart's options. You can modify the color value according to your requirement. The color value can be specified as an RGBA color, HEX color, or any other valid CSS color value.


Make sure to replace ctx with the actual context of your chart canvas and set the other necessary chart properties and data as per your chart's requirements.


How can I customize the tooltip in chart.js?

To customize tooltips in Chart.js, you can use the tooltips configuration option. Here are some ways you can customize the tooltip appearance and behavior:

  1. Changing the background color and font color: tooltips: { backgroundColor: 'rgba(0,0,0,0.8)', bodyFontColor: '#fff' }
  2. Modifying the title and body font styles: tooltips: { titleFontFamily: 'Arial', titleFontSize: 16, bodyFontFamily: 'Arial', bodyFontSize: 14 }
  3. Formatting tooltip labels and values: tooltips: { callbacks: { title: function(tooltipItem, data) { return 'Custom Title:' + tooltipItem[0].label; }, label: function(tooltipItem, data) { return 'Value: ' + tooltipItem.value; } } }
  4. Enabling mode: 'nearest' to always show the tooltip for the nearest data point: tooltips: { mode: 'nearest' }
  5. Disabling the tooltip: tooltips: { enabled: false }


These are just a few examples of how you can customize tooltips in Chart.js. You can explore more tooltip customization options in the Chart.js documentation.
